FOX H1-5.0-E-G2 Hybrid Inverter

Description

The Fox ESS H1-5.0-E-G2 is a 5kW single-phase high-voltage hybrid inverter designed for residential solar and energy storage systems. It features two independent MPPT trackers, EPS (Emergency Power Supply) functionality for backup power during outages, and an IP65 rating for outdoor installation.

Key Technical Specifications

- Rated Output Power: 5,000 W
- Max PV Array Power: up to 10,000 W
- Max DC Input Voltage: 600 V
- MPPT Voltage Range: 80 V – 550 V
- Battery Compatibility: High-voltage lithium-ion (LFP)
- Efficiency: 96.30% system max efficiency
- Weight & Dimensions: 22 kg | 434 x 418 x 185 mm [1, 2, 3, 4]

Standout Features

Battery Expandability: Can be easily scaled by connecting up to 7 high-voltage batteries in series for massive storage capacity.
Smart Monitoring: Fully integrates with the FoxESS app for remote cloud monitoring and over-the-air firmware updates.
Backup Protection: Built-in EPS feature provides 5kW continuous EPS output power to critical loads during grid failures.
Easy Installation: Plug-and-play setup with advanced built-in fuse protection
